4K UHD OTT SoundBox

KOD+

  • Embedded Microphone for Voice Search
  • 2.1 Channel TFAT (Thin Film Acoustic Technology)
  • Speakers Power Outputs (35W MAX.)
  • Karaoke Function: Key Adjust, Echo Adjust, Mic Volume Adjust, Dual MIC, Vocal Cancellation
  • Karaoke Mode Selecting: KTV/ Concert/ Concert hall/ Studio
  • Audio Mode Selecting: Karaoke/ Music/ Movie/ Game

Music

Music streaming to SoundBox from mobile phone / tablet via Bluetooth source

IoT

SoundBox acts as an entry point for IoT in your smart home system.

OTT

By using SoundBox and depending on technical possibilities and video content availability, you can propose to your clients IPTV, VoD services and OTT contents.

Phone Remote / Bluetooth Remote

Connect SoundBox with Bluetooth Remote Control or your smartphone / tablet by downloading TV remote app from iTunes or Google Play.

Antenna
Internal 2 Antennas
Power
Input voltage DC 12V, 3A
System
SOC Dual A53 with 7K + DIMPS
RAM LPDDR4 2GB
Flash 8GB eMMC
WLAN IEEE 802.11a/b/g/n/ac Dual Band
BT Bluetooth 4.2 dual mode (BDR/EDR/BLE)
OS Android / Linux
CA Option
Display up to 4K2Kp60
DSP Amplifier
Output Power 10W x 2+15W x 1
Total Harmonic Distortion < 3%
Signal to Noise > 80dB
Speaker
Satellite

Dimension: 90x30mm 10W x 2 / 4Ω

Sensitivity: 78dB at 0.5Meter/ 1W

Subwoofer

Dimension: 70x70mm 15W x 1 / 4Ω

Sensitivity: 80dB at 1Meter/ 1W

Front Panel
IR Receiver 38KHz IR x1
LED Power/Standby, Ethernet, Wi-Fi, Mode, Bluetooth
USB host USB 2.0 type A receptacle x 1
Microphone 6.3mm Phone Jack x 2
Rear Panel
Power in DC Jack x1
USB host USB 2.0 type A receptacle x1
Ethernet port 10/100Mbps Ethernet, RJ-45 x 1
HDMI output HDMI 2.0a with HDCP 2.2
Aux out 3.5Ø Phone Jack x 1
DTV RF-in (Optional) Support DVB-C/C2/T/T2/S/S2, ISDB-T/C, J.83A/B/C
Dimensions
Casing Size 315.0mm x 171.3mm x 52.7mm
Ambient
Operating Temperature 0°C ~ 40°C
Storage Temperature -40˚C ~ +60˚C

Specifications are subject to change without notice
